TV-M Thermal Vision Module is designated for integration into the completed self-propelled anti-tank systems.

Spectral range is 8-14 mkm.

Receiver type is VOx matrix.

Pixel size is 17 mkm.

Lens focal distance is 150 mm.

Aperture ratio is 1:1.

Angular field of view is 4,2°×3,2°.

Electronic magnification is 2×; 4×.

Detection range of the tank (side projection) is 6000 m.

Recognition range of the tank (side projection) is 4000 m.

Overall dimensions, max – 300х170х185 mm.

Operating temperature range is from -40 to +50 °C.
